Visual Studio Code is an open source and multiplatform IDE for code editing (and compiling, debugging, etc.) available here : https://code.visualstudio.com/

I wanted to see if I could build, run and debug Blender using this IDE, and the anwser is : yes. Here is how to do it.

Edit: Updated the scripts and configuration of Visual Studio Code (no longer requires an CMake install, will load scripts and datafiles directly from the sources)

Setup

Based on : https://wiki.blender.org/index.php/Dev:Doc/Building_Blender/Linux/Generic_Distro/CMake.

I’m using the following folder hierarchy to build:

Blender         # with a B.
   |--- blender # with a b, this is a clone of the Blender source repository
   |--- libs    # will contains Blender's dependencies (external libraries)

So, first step is to create this structure, retrieve the Blender sources, and build the dependencies. To do that, here is the bootstrap script I’m using (put that in a bootstrap.sh file and execute it)

# create our root folder
mkdir Blender
cd Blender

# this will download Blender's sources
git clone --recursive https://git.blender.org/blender.git

# now create the libs folders
mkdir -p libs/sources
mkdir -p libs/install

# and build them. Note that the source and install path need
# to be absolute
./blender/build_files/build_environment/install_deps.sh \
    --with-all                                          \
    --source $PWD/libs/sources                          \
    --install $PWD/libs/install

This can take quite a bit of time, depending on your computer. But you only need to do it once (well, sometime the libs are updated, but it doesn’t happen very often)

Also, after this is done, you’ll notice a file BUILD_NOTES.txt in the root Blender folder. This is a generated file which contains useful information about the dependencies (we’ll use this file to configure Visual Studio Code to build Blender)

Install Visual Studio Code

Once you’ve installed Visual Studio Code, install the following addons :

• C/C++ (Microsoft) – C/C++ support. Required
• CMake (twxs) – CMake syntax coloring, code completion, etc. Optional but useful if you have to modify a CMake script file
• CMake Tools (Microsoft) – Add Configure/Build features based on CMake. Required
• Clang-Format (xaver) – Used to automatically format code to follow Blender’s coding style. Optional but highly recommended if you want to contribute.

Note that CMake Tools plugin requires CMake version 3.7.1 or greater, with server mode enabled (if you installed a recent prebuilt version from the CMake website, it should be enabled by default. But if you build your own, make sure it’s enabled)

Build

Now, open Visual Studio Code, and open the Blender/blender folder. If CMake Tools worked correctly, the status bar should look like this:

Before going further, we will setup the project to configure CMake to use the dependencies. In the sources (Blender/blender) create a .vscode folder. In this folder, create a settings.json file:

{
    // Where Blender is built. DO NOT BUILD IN SOURCES !
    "cmake.buildDirectory": "${workspaceRoot}/../build",

    // If you want to generate an install of Blender, setup this path:
    "cmake.installPrefix":  "${workspaceRoot}/../install"

    // The options used by CMake to configure how Blender is built
    "cmake.configureSettings": {
        // this part comes from the BUILD_NOTES.txt file generated when we build the libs
        "WITH_CODEC_SNDFILE": "ON",
        "PYTHON_VERSION": "3.7",
        "WITH_OPENCOLORIO": "ON",
        // ... the rest of the file
    },

    // Clang-format options (only if your installed the extension)
    "editor.formatOnSave": true,
    "editor.defaultFormatter": "xaver.clang-format"
}

Notice that the options in BUILD_NOTES.txt are not formatted the same way as CMake Tools want, so you need to format them like in the example above.

Now after this step, you’ll be able to build Blender. Just setup the kit you want to use, select the build type (both actions are done using the CMake Tools helpers that appear on the status bar, on the bottom-left of Visual Studio Code) and hit F7

Debug

Time for fun! Blender is built, we’d like to dive in the code. There’s one last thing to do: add a launch configuration. Indeed, unless you make an install, the scripts and datafiles are not accessible to the Blender’s executable. So to debug, we need to create a launch.json next to our settings.json file.

This is the content on my file on Linux, with comments on the relevent sections:

{
    "version": "0.2.0",
    "configurations": [
        {
            "name": "(gdb) Launch",
            "type": "cppdbg",
            "request": "launch",
            // path to the Blender's executable
            "program": "${command:cmake.buildDirectory}/bin/blender",
            // in here you can add arguments that will be passed to blender when the debugging session starts
            "args": [],
            "stopAtEntry": false,
            // by default it runs in the source folder, but you can use any other you like
            "cwd": "${workspaceFolder}",
            // this one is the most important! Without those environment variable, Blender will fail to start because it won't find its Python scripts and data files.
            "environment": [
                { "name": "BLENDER_SYSTEM_SCRIPTS", "value": "${workspaceFolder}/release/scripts" },
                { "name": "BLENDER_SYSTEM_DATAFILES", "value": "${workspaceFolder}/release/datafiles" }
            ],
            "externalConsole": false,
            "MIMode": "gdb",
            "setupCommands": [ { "description": "", "text": "-enable-pretty-printing", "ignoreFailures": true } ]
        }
    ],
    "compounds": []
}

And there, you’re done. Now you can run Blender from inside Visual Studio Code by hitting F5. If you selected a Debug build type, breakpoints will work as excepted, etc.

Conclusion

It was my first time using Visual Studio Code, and I must say I’m very impressed by the ease of use and feature set ! Out of the box, it has Git support, and through the embedded extension manager you can enable C/C++ building/debugging/etc., CMake support, etc. with only a few clicks !

And then the setup part is completely straightforward ! You have a .vscode folder in your project containing the various .json setting files, and in each of those files, autocompletion works like a charm so you can easily find what you want, without even having to bother looking online for documentation / help !! (in my first tests, I was on an old computer where I had to specify the path to my custom CMake, and the path to my custom GDB, and I found them in a few seconds without having to leave the IDE)

Anyway, I highly recommend you to give a try to this software, CMake support is almost perfect (I still have to delete the build folder manually whenever I want to change the options CMake was configured with, but other than that, perfect) and building / debugging is fast, intuitive, user friendly and powerful.

A small post-it on how to change the default location of intellisense databases for Visual Studio. By default, those huge .sdf files (which get updated again and again) are stored next to your project location.

If you’re working on an SSD, or on a slow USB drive, you might want to avoid storing those databases at their usual location (or just to avoid having huge files around, or whatever other reason)

To do that, just go to Tools > Options then on the Text Editor > C/C++ > Advanced tab, locate the section Fallback Location. Here, Always use Fallback Location will need to be set to true to tell Visual Studio to always use the Fallback Location (which you can then set to any folder you want, or leave empty if you want to use the windows temp folder)

You can now close Visual Studio, remove your sdf files, launch it again. It will prompt you about your fallback location, but you just have to click OK and don’t forget to check the Don’t Prompt Me Again checkbox to avoid this at every launch. Tadaaa, no more sdf files next to your projects !

[Source]

In my previous post on how to build Qt on Windows, I explained how to build Qt for Windows, using Visual Studio 2010 and prebuilt ICU libraries. If we want to build Qt with Visual Studio 2013, we’ll need to build ICU ourself, and here’s how :

• Download ICU sources from here : http://site.icu-project.org/download
• Unzip in C:\ (you will have a C:\icu folder with C:\icu\readme.html (among others))
• Go into C:\icu\source\common\unicode, edit platform.h and add the following somewhere at the beginning. It’s needed if you want to build Qt :

#define U_CHARSET_IS_UTF8 1

• Go into C:\icu and create a build.bat file, with the following content and run it :

@echo off

::
:: setup Visual Studio 2013 environment for x64 builds
::
call "C:\Program Files (x86)\Microsoft Visual Studio 12.0\VC\vcvarsall.bat" x86_amd64

::
:: build
::
msbuild source\allinone\allinone.sln /m /target:Build /property:Configuration=Release;Platform=x64
msbuild source\allinone\allinone.sln /m /target:Build /property:Configuration=Debug;Platform=x64

This will build ICU in x64. You can run the same script again and remove the “x86_amd64” argument to the vcvarsall.bat script, and change the Platform property to Win32 to build ICU in x86.

Imagine the following peace of code (which is really simple for the sake of the example :)

for (entity in entities)
{
    glPushMatrix();

    // do some stuff

    glPopMatrix();
}

The basic idea here is that you need to maintain the integrity of a states’ stack in a loop. But what happens if you have some tests that allow to break, continue or return :

for (entity in entities)
{
    glPushMatrix();

    // do some stuff

    if (entity->NeedToDoOtherStuff() == false)
    {
        continue;
    }

    // do some other stuff

    glPopMatrix();
}

Wrong. You didn’t pop the matrix, everything gets corrupted. You need to add a glPopMatrix() right before continue. And the more of those special cases, the more glPopMatrix you need to add. And if you have more states to push / pop, you need to duplicate those too.

This scenario happens a lot in real applications. If you allocate some temporary data to work with, you need to cleanup before exiting the function, and if you have many exit points (error checks, etc.) you end up duplicating cleanup code everywhere, which is error prone and fastidious. You can also use goto’s :)

Here is a little templated class which solves this problem using 2 features of C++11 : lambdas and functional.

class Cleanup
{
public:
    template< typename T >
    inline Cleanup(T && code)
        : m_Code(code)
    {
    }

    inline ~Cleanup(void)
    {
        m_Code();
    }

private:
    std::function< void (void) > m_Code;
};

This class can be used like this :

for (entity in entities)
{
    glPushMatrix();
    Cleanup popMatrix([]() { glPopMatrix(); });

    // do your stuff
    // make some tests, continue or break depending on the reults
    // do other stuff
}

As soon as the Cleanup instance goes out of scope it will execute the code that you gave it. I find this particularly useful :

• no longer crashes when you add an exit point, special case, etc. and forget to copy / paste the cleanup code.
• the cleanup code is defined right at the top of the scope, which in my experience makes it really hard to forget updating it, if you need to add more states, more intermediate data that need cleanup, etc.

If you’re using Visual Studio 2012 or 2013 Express with Qt, you can’t use the Qt Addin, but you might still want to have user friendly Qt types showing in your debugger. Luckily this is quite easily achieved :

1. Download the qt5.natvis file from the Qt Git repository.
2. Make sure you have the following folder : <MyDocuments>\Visual Studio 2013\Visualizers and if not, create it.
3. Copy the qt5.natvis file in it, and restart Visual Studio.
4. Done.

Following is a small script that I use to build a few static Boost libraries in 64 bits for Visual Studio 2012, and with iterator debugging turned off.

:: build the bjam and b2 exe
if not exist "b2.exe" (
    bootstrap.bat
)

:: build boost with visual 2012 toolset.
::   - static lib
::   - multithreaded shared runtime
::
:: it only builds signals and filesystem
b2.exe -a -d0 -j4 toolset=msvc-11.0 address-model=64 variant=debug link=static threading=multi runtime-link=shared define=_HAS_ITERATOR_DEBUGGING=0 --with-signals --with-filesystem
b2.exe -a -d0 -j4 toolset=msvc-11.0 address-model=64 variant=release link=static threading=multi runtime-link=shared define=_HAS_ITERATOR_DEBUGGING=0 --with-signals --with-filesystem

A little note on the build system integrated in Sublime. If you have multiple commands to execute during a build (for instance minifying your js code, and generating the documentation) your can do it quite easily on Windows, but it took me a while to find the equivalent on Mac, so here is the relevent (simplified version) part of my build system:

"windows": {
    "shell": true,
    "cmd": [
        "python", "build.py", "compress", "&;"
        "python", "build.py", "doc"
    ]
},
"osx": {
    "shell": false,
    "cmd": [
        "sh", "-c", "python build.py compress && python build.py doc"
    ]
}

Notice the difference between Windows and OSX. On Windows, you simply add an additional “&;” parameter which will separate the commands, but on OSX (I guess it would be the same on Linux) it doesn’t work. The only way I found to execute multiple commands was to directly call sh with the -c option and put all my commands in a single string. The commands are then separated by a && sequence.

Oh and also shell must be true on Windows, but false on OSX, else nothing runs.
